1. Ergonomic Control Handle: The multi-functional handle integrates all operation buttons, allowing for one-handed operation with either hand; it also features a "snail-speed" driving function to ensure extremely high safety in confined spaces.
2. Modular Maintenance Design: The clear internal layout allows easy access to the battery and hydraulic pump station by opening the outer casing, significantly reducing daily inspection and parts replacement time.
3. Intelligent Energy Recovery: When braking on a slope or releasing the accelerator lever, the system automatically activates energy recovery, converting kinetic energy into electrical energy to recharge the battery, extending the operating time per charge.
4. High Cost-Effectiveness Investment: Compared to off-road models, this product is simpler to maintain, has more interchangeable parts, and offers an excellent return on investment (ROI).
1. Ergonomic Control Handle: The multi-functional handle integrates all operation buttons, allowing for one-handed operation with either hand; it also features a "snail-speed" driving function to ensure extremely high safety in confined spaces.
2. Modular Maintenance Design: The clear internal layout allows easy access to the battery and hydraulic pump station by opening the outer casing, significantly reducing daily inspection and parts replacement time.
3. Intelligent Energy Recovery: When braking on a slope or releasing the accelerator lever, the system automatically activates energy recovery, converting kinetic energy into electrical energy to recharge the battery, extending the operating time per charge.
4. High Cost-Effectiveness Investment: Compared to off-road models, this product is simpler to maintain, has more interchangeable parts, and offers an excellent return on investment (ROI).
| Item | Pallet truck | |
| model | NB20L01HM | NB30L01HM |
| Load capacity | 2000 kg | 3000 kg |
| Total length | 1640 mm | 1710 mm |
| Total width | 560/680 mm | 560/680mm |
| Fork size | 73x160x1150 mm | 73x160x1150mm |
| Load center distance | 600 mm | 600mm |
| Height can be increased | 110 mm | 110mm |
| Ground to fork height | 85(65) mm | 85(65)mm |
| Driving speed (fully loaded/empty) | 4/4.2 km/h | 4/4.2 km/h |
| Turning radius | 1445 mm | 1515 mm |
| weight | 155 kg | 165 kg |
| lithium batteries | 48/20 (30) Ah | 48/20 (30)Ah |
| Item | Pallet truck | |
| model | NB20L01HM | NB30L01HM |
| Load capacity | 2000 kg | 3000 kg |
| Total length | 1640 mm | 1710 mm |
| Total width | 560/680 mm | 560/680mm |
| Fork size | 73x160x1150 mm | 73x160x1150mm |
| Load center distance | 600 mm | 600mm |
| Height can be increased | 110 mm | 110mm |
| Ground to fork height | 85(65) mm | 85(65)mm |
| Driving speed (fully loaded/empty) | 4/4.2 km/h | 4/4.2 km/h |
| Turning radius | 1445 mm | 1515 mm |
| weight | 155 kg | 165 kg |
| lithium batteries | 48/20 (30) Ah | 48/20 (30)Ah |


1. Busy Sorting Centers: A lightweight steering system supports high-frequency truck loading and unloading operations for up to 8 hours a day, minimizing downtime.
2. Narrow Retail Warehouses: A compact design allows for fine-tuning of the fork's vertical angle, easily navigating the confined spaces between supermarket shelves.
3. Manufacturing Production Lines: Stable power output and precise start-stop control ensure accurate flow of raw materials between workstations, preventing goods from tipping over and causing injury.
1. Busy Sorting Centers: A lightweight steering system supports high-frequency truck loading and unloading operations for up to 8 hours a day, minimizing downtime.
2. Narrow Retail Warehouses: A compact design allows for fine-tuning of the fork's vertical angle, easily navigating the confined spaces between supermarket shelves.
3. Manufacturing Production Lines: Stable power output and precise start-stop control ensure accurate flow of raw materials between workstations, preventing goods from tipping over and causing injury.
